With the traffic stream, vs | plus is able to switch the signal groups at the intersection and react to the detectors or message points.
Figure 27: The traffic stream element
|
Display |
Identifier |
Values |
Description |
|
ID No |
ID Number |
|
For identification purposes, a unique number must be assigned to each traffic stream. It is mandatory to assign the properties Kind to each defined traffic stream. |
|
|
|
|
|
|
|
1 .. 64 / 96 |
|
|
|
Name |
Names of the Traffic Streams |
|
Must be unique. |
|
Kind |
Traffic Stream type |
|
The kind is used to define the behavior of the traffic stream. |
|
|
|||
|
|
INAC |
The traffic stream is inactive and has no effect on vs | plus. |
|
|
|
MT |
Motor vehicles. The traffic stream is considered as a request and measurement system. Detectors with the INAC, NORM, REDwJAM, EXTwJAM and SOFT detector functions can be assigned. Special feature: Special treatment during Lead. |
|
|
|
MTCOC |
Motor vehicles with switch-on return. The traffic stream is considered as a request and measurement system. Detectors with the INAC, NORM, REDwJAM, EXTwJAM and SOFT detector functions can be assigned. A switch-on command is cancelled if the request is withdrawn during switch-on (e.g., no more occupancy). Special feature: Special handling during Lead. |
|
|
|
BI |
Bicycle. The traffic stream is considered as a request and measurement system. Detectors with the INAC, NORM, REDwJAM, EXTwJAM and SOFT detector functions can be assigned. Special feature: Special treatment during Lead. |
|
|
|
PED |
Pedestrians. The traffic stream is considered as a request and measurement system. Detectors with the INAC, NORM, REDwJAM, EXTwJAM and SOFT detector functions can be assigned. Special feature: special treatment during Lead. |
|
|
|
DPED |
Pedestrian with center island. The traffic stream is considered as a request and design system. Detectors with the INAC, NORM, REDwJAM, EXTwJAM and SOFT detector functions can be assigned. Special feature: green times are used to control walking times. |
|
|
|
DPEDe |
Pedestrians entering with center island. The traffic stream is considered as a request and design system. Detectors with the INAC, NORM, REDwJAM, EXTwJAM and SOFT detector functions can be assigned. Special feature: green times are used to control walking times. |
|
|
|
DPEDc |
Pedestrian with center island clearing. The traffic stream is considered as a request and design system. Detectors with the INAC, NORM, REDwJAM, EXTwJAM and SOFT detector functions can be assigned. Special feature: green times are used to control walking times. |
|
|
|
PT |
Check-in / check-out systems with message points parallel only. The traffic stream is considered as a check-in / check-out system. Message points in parallel can be assigned. Special feature: Special handling during Lead. |
|
|
|
PT-M |
The traffic stream is considered as a check-in and check-out system. Message points serial or parallel can be assigned. Special feature: Special treatment during Lead. |
